AMUTIO CAZENEUVE HB725x6000

RECONSTRUCTED Amutio Cazeneuve HB725x6000 Lathe
Country
Share
Ask for price On request
Condition Used - Working

Machine data

Condition Used - Working
Price type On request

Technical specifications

Weight 5.600 kg
Length 7.640 mm
Width 1.270 mm
Height 1.355 mm
Swing diameter 725 mm
Distance between centers 6.000 mm
Bar capacity 81 mm

Occasional seller

M
Maquinaria Industrial Donosti SL Private seller
Member since 2017
51 ads online

SEND REQUEST

CAZENEUVE AMUTIO HB725x6000
CAZENEUVE AMUTIO HB725x6000

Distance between centers: 6000mm.
Swing over bed: 725mm.
Swing over cross slide: 670mm.
Swing over cross slide (transverse): 400mm.
Center height: 315mm.
Bed width: 505mm.
Spindle bore: 81mm.
Tailstock taper: CM-6
Number of spindle speeds: 18.
Maximum cross slide travel: 400mm.
Maximum compound rest travel: 220mm.
Maximum tailstock quill travel: 235mm.
Machine dimensions: 7640x1270x1355.
Motor power (HP): 25-20-15.
Machine weight: 5600Kgs.
Chuck and cross slide guards and CE certificate. (Optional full enclosure)
Equipped with new chuck and steady rest.
Optional Fagor or Heidenhain readout.
Warranty: 1 year.

53000 euros

  • Condition
    Used

  • Seller's country
    Spain
  • State
    Used - Functional
  • Weight
    5,000 - 10,000 kg
  • Long
    More than 5,000 mm
  • Width
    1,000 - 2,000 mm
  • High
    Up to 1,500 mm
  • Turning diameter
    500 - 800 mm
  • Distance between points
    More than 2,000 mm
  • Bar feed
    65 - 100 mm
