LACFER CR2 E-250 LATHE (RECONDITIONED)

PRODUCTION LATHE FOR CYLINDRICAL TURNING AND THREADING
Country
Share
Ask for price On request
Condition Used - Working

Machine data

Condition Used - Working
Price type On request

Technical specifications

Swing diameter 500 mm
Distance between centers 2.000 mm
Bar capacity 60 mm
Spindle power 7,46 kW
Number of axes 2 ejes

Occasional seller

T
Talleres ARAY, S.L. Private seller
Member since 2017
6 ads online

SEND REQUEST

TORNO LACFER CR2 E-250 (RECONSTRUIDO)
TORNO LACFER CR2 E-250 (RECONSTRUIDO)

• 500 mm x 2000 mm E.P. with a 740 mm swing over bed.

• 60 mm bore, mounted on precision
bearings.
• 16 speeds from 18 to 1600 r.p.m.
• Quick-change turret with 4 tool posts.
• 10 HP motor.
• Main spindle with chuck mounting according to DIN
55022-6” standards.
• Hardened bed of 400-500 Brinell and ground.
• Hardened and ground gears.
• Automatic lubrication to the longitudinal carriage.
• M 6 lead screw.
• "Goizper" electromagnetic clutches.
• Ground cross slide, prepared for stops and
rear turret.
• Hardened and ground tailstock quill, locking
by eccentric.
• Commercial guards according to Royal Decree
1215/97.
• Fagor two-axis digital readout:

Guards for the scales.

  • Condition
    Used

  • Seller's country
    Spain
  • State
    Used - Functional
  • Spindle power
    5 - 15 kW
  • Number of axes
    2 axes
  • Turning diameter
    500 - 800 mm
  • Distance between points
    More than 2,000 mm
  • Bar feed
    40 - 65 mm
