Diana 25 (624063)

Correa
The CORREA DIANA25 fixed-bed milling machine was designed for sectors that require not only high versatility and rigidity in machining but also optimal finishing conditions.

Fully overhauled milling machine, with excellent geometry and precision conditions. Guaranteed.
Country
Share
Ask for price On request
Condition Used - Working

Machine data

Manufacturer CORREA
Condition Used - Working
Hours of use 50 h
Price type On request

Technical specifications

Length 7.114 mm
Width 5.070 mm
Height 2.803 mm
Spindle speed 3.000 rpm
Spindle power 22 kW
Spindle taper ISO 50

Occasional seller

N
NC SERVICE MILLING MACHINES, S.A. Private seller
Member since 2017
33 ads online

SEND REQUEST

Diana 25 (624063)
Diana 25 (624063)
Diana 25 (624063)
Diana 25 (624063)
Diana 25 (624063)
Diana 25 (624063)

Fixed bed milling machine CORREA DIANA 25
Year of manufacture: 2008
Condition: Overhauled
CNC control: HEIDENHAIN TNC-i530
Table dimensions: 2800 x 900 mm
Number of T-slots: 5
T-slot dimensions: 22 mm
X-axis travel: 2,500 mm
Y-axis travel: 1,000 mm
Z-axis travel: 1,000 mm
Spindle head model: Universal automatic UDG (2.5º)
Tool clamping: Hydraulic
Taper: ISO 50 (DIN69871)
Speed range: 3,000 rpm
Spindle power: 22 kW
Rapid traverses (X / Y, Z): 20,000 mm/min
Maximum table load: 4,000 kg
Approximate machine weight: 15,000 kg
Machine dimensions: 7,114 x 5,070 x 2,803 mm
ACCESSORIES:
Enclosure
Automatic tool changer: ATC-30
Electronic handwheel: HR-410
Through-spindle coolant: High pressure
Coolant tank and cleaning unit
Chip conveyor: longitudinal
Warranty: Mechanical parts 6 months
Sale price (Ex Works): Consult

  • Brand
  • Condition
    Used

  • Year
    2008
  • CNC
    HEINDENHAIN
  • Cone type:
    ISO-50
  • X travel (mm)
    2500
  • Y travel (mm)
    1000
  • Hours of use
    0 - 100
  • Chip extractor
    YES
  • Table size (width) (mm)
    900
  • Tool changer (num tools)
    I need the text you want translated. Please provide it.
  • Weight (kg)
    15,000
  • Seller's country
    Spain
  • State
    Used - Functional
  • Hours of use (value)
    I need the text you want me to translate. You only wrote "50". Please provide the full text you'd like translated from Spanish to English.
  • Weight
    Up to 500 kg
  • Long
    More than 5,000 mm
  • Width
    More than 3,000 mm
  • High
    2,500 - 3,500 mm
  • X Travel
    Up to 500 mm
  • Y travel
    Up to 300 mm
  • Z travel
    Up to 300 mm
  • Spindle speed
    3,000 - 8,000 rpm
  • Spindle power
    15 - 30 kW
  • CNC spindle cone
    ISO 50
