A25/25 (9253906)

Correa
CORREA A25/25 milling machine fully mechanically rebuilt, with installation of a new automatic head and new HEIDENHAIN CNC. It features an automatic tool changer, resulting in a versatile milling machine ideal for robust and precise machining.

Rebuilt milling machine for sale with warranty.
Country
Share
Ask for price On request
Condition Used - Working

Machine data

Manufacturer CORREA
Condition Used - Working
Price type On request

Technical specifications

Length 6.590 mm
Width 4.920 mm
Height 2.700 mm
Spindle speed 3.000 rpm
Spindle power 22 kW
Spindle taper ISO 50

Occasional seller

N
NC SERVICE MILLING MACHINES, S.A. Private seller
Member since 2017
33 ads online

SEND REQUEST

A25/25 (9253906)
A25/25 (9253906)
A25/25 (9253906)
A25/25 (9253906)
A25/25 (9253906)

CORREA A 25/25 Bed Milling Machine
Year of manufacture: 1998
Year of rebuild: 2019
New! HEIDENHAIN TNC-320.

Table dimensions: 3,500 x 1,000 mm
Number of T-slots: 7
T-slot dimensions: 22 mm

X-axis travel: 3,000 mm
Y-axis travel: 1,200 mm
Z-axis travel: 1,500 mm

Spindle head model: NEW! Universal automatic UDG (2.5º)
Tool clamping: Hydraulic
Taper: ISO 50 (DIN69871)
Speed range: 20 – 3,000 rpm
Spindle power: 22 kW

Working feeds: 5 - 5,000 mm/min
Rapid traverses (X / Y, Z): 8,000 mm/min / 10,000 mm/min

Maximum table load: 7,000 kg
Approximate machine weight: 18,000 kg
Machine dimensions: 6,590 x 4,920 x 2,700 mm

ACCESSORIES:

Enclosure
Automatic tool changer: ATC-30
Electronic handwheel: New HR-510
Coolant: External and internal high pressure through spindle.
New pump and new tank.

Warranty: Mechanical spare parts 6 months
Sale price (Ex Works): Inquire

  • Brand
  • Condition
    Used

  • Year
    1998
  • Cone type:
    ISO-50
  • X travel (mm)
    2500
  • Y travel (mm)
    1200
  • Table size (width) (mm)
    1000
  • Tool changer (num tools)
    I need the text you want translated. Please provide it.
  • Weight (kg)
    18000
  • Seller's country
    Spain
  • State
    Used - Functional
  • Weight
    Up to 500 kg
  • Long
    More than 5,000 mm
  • Width
    More than 3,000 mm
  • High
    2,500 - 3,500 mm
  • X Travel
    Up to 500 mm
  • Y travel
    Up to 300 mm
  • Z travel
    Up to 300 mm
  • Spindle speed
    3,000 - 8,000 rpm
  • Spindle power
    15 - 30 kW
  • CNC spindle cone
    ISO 50
