CF40/50 (7700212)

Correa
Fixed bed milling machine CORREA CF40/50 (S/N: 7700212)

This CORREA CF40/50 milling machine, featuring roller slides and linear guides for the X-Z axis movement, achieves high dynamic performance for machining large-sized parts.

The retrofitting option, with the installation of a new automatic milling head and a new HEIDENHAIN TNC-320 numerical control, turns it into a fully updated alternative for a customer demanding the timeless quality of CORREA CNC milling machines, with the most modern features.
Country
Share
Ask for price On request
Condition Used - Working

Machine data

Manufacturer CORREA
Condition Used - Working
Hours of use 50 h
Price type On request

Technical specifications

Length 5.200 mm
Width 2.900 mm
Height 2.760 mm
X travel 5.000 mm
Y travel 1.200 mm
Z travel 1.500 mm
Spindle speed 2.500 rpm
Spindle power 30 kW
Spindle taper ISO 50

Occasional seller

N
NC SERVICE MILLING MACHINES, S.A. Private seller
Member since 2017
33 ads online

SEND REQUEST

CF40/50 (7700121)
CF40/50 (7700121)
CF40/50 (7700121)
CF40/50 (7700121)
CF40/50 (7700121)
CF40/50 (7700121)
CF40/50 (7700121)

CORREA CF40/50 Fixed Bed Milling Machine (S/N: 7700212)
Year of manufacture: 1991
Condition: rebuilt
HEIDENHAIN TNC-415 CNC control (option: new TNC-320)
Table dimensions: 5,000 x 1,000 mm
Number of T-slots: 8
T-slot dimensions: 22 mm
Longitudinal travel X: 5,000 mm
Cross travel Y: 1,200 mm
Vertical travel Z: 1,500 mm
Head: Universal manual (Option: new UDG (2.5º))
Tool clamping: Hydraulic
Taper: ISO50
Speed range: 20 – 2,500 rpm
Spindle power: 30 kW
Working feeds: 1 - 5,000 mm/min
Rapid traverses (X / Y, Z): 15,000 mm/min
Maximum table load: 12,000 kg
Approximate machine weight: 27,000 kg
Machine dimensions: 5,200 x 2,900 x 2,760 mm
ACCESSORIES:
Electronic handwheel: HR-410
Enclosure
Sales conditions:
Warranty: Mechanical parts 6 months
Sale price (Ex Works): Inquire

  • Brand
  • Condition
    Used

  • Year
    1991
  • Cone type:
    ISO-50
  • X travel (mm)
    5000
  • Y travel (mm)
    1200
  • Hours of use
    0 - 100
  • Chip extractor
    NO
  • Table size (width) (mm)
    1000
  • Weight (kg)
    27000
  • Seller's country
    Spain
  • State
    Used - Functional
  • Hours of use (value)
    I need the text you want me to translate. You only wrote "50". Please provide the full text you'd like translated from Spanish to English.
  • Weight
    Up to 500 kg
  • Long
    More than 5,000 mm
  • Width
    2,000 - 3,000 mm
  • High
    2,500 - 3,500 mm
  • X Travel
    More than 3,000 mm
  • Y travel
    More than 1,000 mm
  • Z travel
    More than 800 mm
  • Spindle speed
    Up to 3,000 rpm
  • Spindle power
    More than 30 kW
  • CNC spindle cone
    ISO 50
