CNC Vertical Lathe with C-axis TOSHULIN

Manufactured: TOS-HULIN
Model: SKA-12
YOM: 2000
CNC: Siemens 840C (with TFT-10 monitor)
Chuck diameter: 1,250 mm
Maximum turning diameter: 1,400 mm
Maximum turning height: 1,900 mm
Minimum drilling diameter: 320 mm
RPM: 630
Main motor power: 63 Kw
Speed ranges: 2
Maximum permissible weight: 8,000 kg
C-axis: YES
Tool magazine: 88 for ISO 50, refer to Widiaflex tool holders
Rapid traverse: 12,000 mm/min
Feed speed range: 0-12,000 mm/min
Milling head included
OPTIONAL EXTRAS INCLUDED:
Renishaw active tool control
Renishaw active part control (2)
Front chip conveyor
Hydraulic 4-jaw chuck with 1,250 mm diameter
50 bar pressure in cooling equipment
High precision package on axes (X - Z) 0.01 - m. Machine equipped with linear scales.
Supplementary power for rotating tools up to 20 Kw
KNOLL 150 - 1,000 liter ecological rotary filter - min. Precision filtration
Cooling system for cutting fluid.
MODIFICATIONS MADE:
- Steel chuck with 4 jaws of 1,250 mm diameter, instead of a cast iron chuck and with double T system Ref. STD 009500B
- 88-station tool magazine for ISO 50 tools and Widiaflex tool holders
- Rapid traverse increased to 12 m/min
- 1000 liter emulsion tank.
- SIEMENS mini hand unit mod. BHG
- HEIDENHAIN encoder with 140,000 pulses instead of 80,000 as standard.
- RENISHAW measuring system with dual head, horizontal and vertical.
- New SIEMENS CNC monitor mod. TFT-10.
- Motorized CNC control panel with elevation and rotation at 45° position
- Special tool storage and loader.
