L30/104 (7901103)

CORREA L30/104 moving column milling machine (7901103)
Year of manufacture: 1998
Status: Overhauled
CNC control HEIDENHAIN TNC-426
Table dimensions: 12,240 x 1,000 mm
Number of T-slots: 6
T-slot dimensions: 22 mm
Longitudinal travel X: 10,450 mm
Cross travel Y: 1,200 mm
Vertical travel Z: 2,500 mm
Spindle head model: Universal Automatic UDG-40 (every 2.5º)
Tool clamping: Hydraulic
Taper: ISO 50
Speed range: 20 – 3,000 rpm
Spindle power: 30 kW (1204 Nm)
Working feeds: 20 - 5,000 mm/min
Rapid traverses (X/Y, Z): 10,000 mm/min
Maximum weight on table: 42,000 kg
Approximate machine weight: 45,000 kg
Machine dimensions: 16,000 x 5,600 x 4,830 mm
Enclosure: Not included. To be defined according to customer needs.
Automatic tool changer: ATC-60
External and internal coolant through the spindle
Longitudinal chip conveyor
Electronic handwheel: HR-410
Rotary table: Dimensions: 1,200 x 1,200 mm / H: 368 mm
Indexing: +/- 3 sec / Maximum load: 5,000 kg / V: 3.7 rpm
Warranty: Mechanical spare parts 6 months
Sale price (Ex Works): Consult
