FPM60 (8800901)

Correa
CORREA FPM60 Gantry Milling Machine
Year of manufacture: 1995
Year of reconstruction: 2019
Numerical control: Heidenhain TNC-426
Country
Share
Ask for price On request
Condition Used - Working

Machine data

Manufacturer CORREA
Condition Used - Working
Hours of use 50 h
Price type On request

Technical specifications

Weight 75.000 kg
Length 15.300 mm
Width 6.550 mm
Height 6.180 mm
X travel 6.000 mm
Y travel 3.800 mm
Z travel 1.000 mm
Spindle speed 2.000 rpm
Spindle power 30 kW
Spindle taper ISO 50

Occasional seller

N
NC SERVICE MILLING MACHINES, S.A. Private seller
Member since 2017
33 ads online

SEND REQUEST

FPM60 (8800901)
FPM60 (8800901)
FPM60 (8800901)
FPM60 (8800901)
FPM60 (8800901)
FPM60 (8800901)
FPM60 (8800901)
FPM60 (8800901)
FPM60 (8800901)

Table dimensions: 6,000 x 2,500 mm
Number of T-slots: 10
T-slot dimensions: 22 mm
Longitudinal travel X: 6,000 mm
Cross travel Y: 3,800 mm
Clearance between columns: 3,370
Vertical travel Z: 1,000 mm
Head: Automatic universal UDG40 (every 3°)
Tool clamping: Hydraulic
Taper: ISO 50
Speed range: 20 – 2,000 rpm
Spindle power: 30 KW
Working feeds: 2 - 5,000 mm/min
Rapid traverse X-Y, Z: 7,200 mm/min
Maximum weight on table: 15,000 kg/m²
Approximate machine weight: 75,000 kg
Machine dimensions: 15,300 x 6,550 x 6,180 mm
Enclosure
Automatic tool changer: ATC-60
Coolant: External
2 longitudinal chip conveyors
Electronic handwheel: HR-410
Warranty: Mechanical parts 6 months
Sale price (Ex Works): Consult

  • Brand
  • Condition
    Used

  • Year
    1995
  • X travel (mm)
    6000
  • Y travel (mm)
    I'm sorry, but you haven't provided any text to translate. The input only contains "3799", which appears to be a number. Could you please provide the full text you'd like me to translate from Spanish to English?
  • Hours of use
    0 - 100
  • Chip extractor
    YES
  • Table size (width) (mm)
    2500
  • Tool changer (num tools)
    I need the text you want me to translate. Please provide it.
  • Weight (kg)
    75,000
  • Seller's country
    Spain
  • State
    Used - Functional
  • Hours of use (value)
    I need the text you want me to translate. You only wrote "50". Please provide the full text you'd like translated from Spanish to English.
  • Weight
    More than 10,000 kg
  • Long
    More than 5,000 mm
  • Width
    More than 3,000 mm
  • High
    More than 3,500 mm
  • X Travel
    More than 3,000 mm
  • Y travel
    More than 1,000 mm
  • Z travel
    More than 800 mm
  • Spindle speed
    Up to 3,000 rpm
  • Spindle power
    More than 30 kW
  • CNC spindle cone
    ISO 50
