3-jaw self-centering chucks with double guide

3-jaw double guide chucks
Flange - manual control
• spindle with internal clamping jaws
(Ref. Catalog Part 05 - Page 11).
• external socket jaw chuck
(Ref. Catalog Part 06 - Page 11).
• spindle with sliders (false labels) with terminal screw bolts shown
(Ref. Catalog Part 11-15 - Page 11)
Can be supplied in the following versions
• 3 + 3 jaws (3 + 3 internal socket, external socket)
• 3 + 3 + 3 jaws (3 + 3 internal socket, external socket + 3 sliders complete with base screw terminals)
• 3 terminal support sliders (screw terminals on request)
• Front attachment: n. 3-6 standard holes
• Front attachment: n. 4 holes at 90° up to ∅ 250
For information, call Luigi De Pra +39 3472234516, +39 990 044 0437.
