MANDRINADORA SACEM MS 110

Main spindle inner cone: ISO 50.
Longitudinal displacement of main spindle (cane): 900 mm
Vertical Spindle Stroke: 1800 mm
Minimum and maximum speed: 5 to 1000.
Dimensions of the turntable: 1,260 x 1,400 mm.
Fast travel for X, Y, Z and W axes: 5,000 mm-min.
Cross table travel: 2000 mm
Longitudinal course of the table: 1,500 mm.
Fast running on all movements: 2,000 mm-min.
Weight allowed on the table: 8,000 Kg Vertical stroke of the head: 1,400 mm.
Power of the drive motor: 25 HP
