CNC Vertical Machining Center MORI SEIKI mod. NV5000 B/40

Manufacturer: Mori Seiki
Model: NV 5000 B-40
YOM: 2005
Control: Fanuc MSG-501
Country
Share
Ask for price On request
Condition Used - Working

Machine data

Condition Used - Working
Price type On request

Technical specifications

Length 2.710 mm
Width 2.788 mm
Height 2.603 mm
X travel 1.020 mm
Y travel 510 mm
Spindle speed 14.000 rpm
Spindle power 22,37 kW
Tool changer slots 30

Occasional seller

M
Metalequip Private seller
Member since 2017
40 ads online

SEND REQUEST

CNC Vertical Machining Center MORI SEIKI mod. NV5000 B/40
CNC Vertical Machining Center MORI SEIKI mod. NV5000 B/40

Table size: 1320x600 mm
Maximum table load: 1200 kg
X-axis travel: 1020 mm
Y-axis travel: 510 mm
Z-axis travel: 510 mm
Spindle nose to table: 150 - 660 mm
Minimum spindle speeds: 40 - 14,000 rpm
Spindle taper: 40 Taper
Main motor (30 min-continuous): 30-25 HP
Tool storage capacity: 30 ATC
Maximum tool diameter: 80 mm
Rapid traverse (X-Y-Z): 1,653 IPM
Cutting feed rate: 787 IPM
Coolant tank capacity: 275 l
Dimensions: footprint (Width x Length): 2788x2710x2603 mm
Weight: 6960 kg

  • Condition
    Used

  • Year
    2005
  • CNC
    FANUC
  • X travel (mm)
    1020
  • Y travel (mm)
    510
  • Z travel (mm)
    510
  • Table size (width) (mm)
    600
  • Table size (length) (mm)
    1320
  • Seller's country
    Poland
  • State
    Used - Functional
  • Weight
    5,000 - 10,000 kg
  • Long
    2,000 - 3,000 mm
  • Width
    2,000 - 3,000 mm
  • High
    2,500 - 3,500 mm
  • X Travel
    1,000 - 2,000 mm
  • Y travel
    300 - 600 mm
  • Z travel
    500 - 800 mm
  • Spindle speed
    8,000 - 15,000 rpm
  • Spindle power
    15 - 30 kW
  • Tool changer
    30 - 60
