1525 CNC

Vertical Turret Lathe
The machine is used for a variety of turning and drilling operations:
- turning of cylindrical and conical surfaces;
- boring;
- facing;
- chamfering;
- cutting;
- machining of parts with curved surfaces (coordinates controlled jointly by two axes);
- Threading - CNC Option
The machine is used for processing metallic and non-metallic materials with high precision and constant cutting speed.
Given the ease and simplicity of service, the machine has high resource efficiency.
Swing diameter, mm (in) 2500 (99")
Faceplate diameter, mm (in) 2250 (88")
Swing height, mm (in) 1600 (63")
Workpiece weight, kg 13000
Vertical ram stroke, mm (in) 1200 (47.24")
Right slide cutting force, kN 41.7
Left slide cutting force, kN 32.9
Cutting force of both supports, kN 65.7
Rapid traverse (for supports), m/min 0.005-1.8
Rapid traverse (for crossrail), m/min 0.36
Faceplate speed, RPM 1.6-110
Support swivel angle, degrees ±30
Tool size, mm (in) 50x50 (2x2")
Main drive power, kW 55
Machine weight, kg 35500
Adjusting screws
Karusselldrehmaschine - Doppelstaender
Umlaufdurchmesser - 2500 mm
Planos de copa - 2250 mm
Drehhoehe - 1600 mm
Max. Stoesselhub - 1200 mm
Lichter durchgang planscheibe bis querbalken - 1700 mm
Max. Werkstueckgewicht - 13 Ton.
Planscheibendrehzahlbereich - 1,6 - 110 UpM
Antrieb hauptmotor - 55 KW
Maschinengewicht - 35,5 Ton.
