MAZAK model INTEGREX 400 III ST

USES 8 CNC axes, CNC lathe with headstock and grinding counter-spindle.
Country
Share
Ask for price On request
Condition Used - Working

Machine data

Condition Used - Working
Price type On request

Technical specifications

Swing diameter 850 mm
Distance between centers 1.524 mm
Bar capacity 102 mm
Spindle power 30 kW
Number of axes 5+ ejes

Occasional seller

M
MASTER GROUP Srl Private seller
Member since 2017
54 ads online

SEND REQUEST

MAZAK model INTEGREX 400 III ST
MAZAK model INTEGREX 400 III ST
MAZAK model INTEGREX 400 III ST
MAZAK model INTEGREX 400 III ST
MAZAK model INTEGREX 400 III ST
MAZAK model INTEGREX 400 III ST

YEAR: 2004
MAXIMUM turning diameter: 850 mm
MAXIMUM turning length: 1524 mm
MAXIMUM turning diameter: 760 mm
BAR capacity: 102 mm
SPINDLE: 35-3300 rpm; 30 kw; 304 mm
COUNTER spindle: 35-4000 rpm; 26 kw; 254 mm
HEAD: CAPTO C6; 15-12000 rpm; 18.5 kw
X-axis travel 1: 630 mm
X-axis travel 2: 230 mm
Y-axis travel: 230 mm
Z1-axis travel: 1585 mm
Z2-axis travel: 1530 mm
RAPID traverse X-Y-Z: 38-26-38 m/min
TOOL MAGAZINE: 80 POS
CONTROL UNIT: MAZATROL 640MT PRO
ACCESSORIES: CHIP CONVEYOR; HIGH-PRESSURE COOLANT; TOOL PRESETTER; RENISHAW LASER PROBE
Note: Automatic load/unload storage system with gantry ROBOT MAZAK mod. FLEX-GL500F head change system capacity 50 Kg included

  • Seller's country: Italy
  • State: Used - Functional
  • Spindle speed: 3,000 - 8,000 rpm
  • Spindle power: More than 30 kW
  • Number of axes: 5+ axes
  • Turning diameter: More than 800 mm
  • Distance between points: 1,000 - 2,000 mm
  • Bar feed: More than 100 mm
  • Condition: Array
  • Weight: 0.000000
