Schuler SP 250

-Press force: 2500 kN;

-Year 1985;

-Double position decoiler, maximum coil weight 7500 kg;

-Coil outer diameter 800... 1250 mm;

-Coil inner diameter (haspel adjustment) 460... 530 mm;

-Straightener and feeder coil width 250..1250 mm (1300);

-Straightener and feeder coil thickness (0.3) 0.5... 1.6 (2.0) mm;

-Tensile strength 400 N/mm2;

-Length (@ 270 º) feed 0... 1250 mm @ 35 spm;

-Punching variable speed 0... 50 spm;

-Closing height SDAU 520 mm;

-Insert movement 70 / 250 mm;

-Slide adjustment 160 mm;

-Slide dimensions 1600 x 1600 mm;

-Ejector force 200 kN;

-Ejector stroke 10 mm;

-Reinforcement plate dimension 1600 x 1600 x 180 mm;

-Scrap in bed 760 x 960 mm;

-Main unit 33 kW;

-Power supply 400V / 250A 50 Hz;

-General height floor level 5050 mm;

-General passage area of the blanking line (W x L) 8800 x 16700 mm;

-General weight 58,000 kg;

-"CE" marking yes;

-Remark: capital modernization stacking & PLC Simatec S7 2009;
