Reconstructed Amutio Cazeneuve HB575 lathe of 1500

CNC lathe Amutio Cazeneuve rebuilt, model HB575 with 1500 between centers, with CE adaptation and certification and 1 year warranty.
Country
Share
Ask for price On request
Condition Used - Working

Machine data

Condition Used - Working
Price type On request

Technical specifications

Weight 1.900 kg
Length 2.905 mm
Width 1.175 mm
Height 1.345 mm
Swing diameter 575 mm
Distance between centers 1.500 mm
Bar capacity 51 mm

Occasional seller

M
Maquinaria Industrial Donosti SL Private seller
Member since 2017
51 ads online

SEND REQUEST

Reconstructed lathe Cazeneuve Amutio HB575 1500

Rebuilt lathe.
Swing over bed: 575mm.
Swing over carriage: 525mm.
Swing over cross slide: 300mm.
Height of centers: 250mm.
Distance between centers: 1500mm.
Spindle bore diameter: 51mm.
Number of spindle speeds: 18.
Tailstock taper: MT-5
Bed width: 400mm.
Maximum cross slide travel: 305mm.
Maximum compound rest travel: 140mm.
Maximum tailstock quill travel: 150mm.
Motor power HP: 12.5-10-7.
Machine weight: 1900 kgs.
Machine dimensions: 2905x1175x1345.
Equipped with new chuck and steady rest.
Chuck and carriage guards and CE certificate. (Optional full enclosure)
Optional DRO.
Warranty: 1 year.
