WM250AV-Fx550 Lathe

High-quality compact lathe. 550 mm between centers. Variable speed drive. 3-speed gearbox in oil bath. Forward/reverse feed allowing left-hand threads. Automatic longitudinal and cross feed.
Country
Share
Ask for price On request
Condition Used - Working

Machine data

Condition Used - Working
Price type On request

Technical specifications

Swing diameter 250 mm
Distance between centers 550 mm
Bar capacity 26 mm
Spindle power 0,75 kW

Occasional seller

I
ionel rusu Private seller
Member since 2017
2 ads online

SEND REQUEST

Torno WM250AV-Fx550

Swing Diameter 250 mm
Max. Diameter over Cross Slide 145 mm
Distance Between Centers 550 mm
Bed Width 135 mm
Longitudinal Travel 450 mm
Headstock Taper MT4
Bar Capacity 26 mm
Maximum Tool Size 20 mm
Speeds 100 - 2,000 rpm
Metric Thread Range 0.4 - 3 mm
Imperial Thread Range 10 - 44 tpi
Tailstock Taper MT2
Motor 1 HP / 0.75 kW / 230 V
Weight 125 kg

Included Accessories
125 mm Reversible 3-Jaw Chuck
125 mm 4-Jaw Chuck
Faceplate
MT2 Live Center
Fixed and Traveling Steady Rests
Chip Tray
Tailstock Quick Lock
Two Dead Centers
Tool Box
Set of Cutting Tools
Set of Change Gears

  • Seller's country: Spain
  • State: Used - Functional
  • Weight: Up to 500 kg
  • Spindle power: Up to 5 kW
  • Turning diameter: Up to 300 mm
  • Distance between points: 500 - 1,000 mm
  • Bar feed: Up to 40 mm
  • Condition: Array
  • Weight: 0.000000
