AMUTIO CAZENEUVE HB810x3000

RECONSTRUCTED Amutio Cazeneuve HB810x3000 Lathe
Country
Share
Ask for price On request
Condition Used - Working

Machine data

Condition Used - Working
Price type On request

Technical specifications

Weight 3.850 kg
Length 4.640 mm
Width 1.270 mm
Height 1.405 mm
Swing diameter 810 mm
Distance between centers 3.000 mm
Bar capacity 81 mm

Occasional seller

M
Maquinaria Industrial Donosti SL Private seller
Member since 2017
51 ads online

SEND REQUEST

CAZENEUVE AMUTIO HB810x3000

Distance between centers: 3000mm.
Swing over bed: 810mm.
Swing over cross slide: 770mm.
Swing over cross slide (transversal): 500mm.
Center height: 365mm.
Number of spindle speeds: 18.
Spindle bore diameter: 81mm.
Tailstock taper: CM-6
Bed width: 505mm.
Maximum cross slide travel: 400mm.
Maximum compound rest travel: 220mm.
Maximum tailstock quill travel: 235mm.
Machine weight: 3850Kgs.
Motor power HP: 25-20-15.
Machine dimensions: 4640x1270x1405.
Equipped with new chuck and steady rest.
Chuck and carriage guards and CE certificate. (Optional full enclosure)
Optional Fagor or Heidenhain DRO.
Warranty: 1 year.

36000 euros

  • Condition
    Used

  • Seller's country
    Spain
  • State
    Used - Functional
  • Weight
    2,500 - 5,000 kg
  • Long
    3,000 - 5,000 mm
  • Width
    1,000 - 2,000 mm
  • High
    Up to 1,500 mm
  • Turning diameter
    More than 800 mm
  • Distance between points
    More than 2,000 mm
  • Bar feed
    65 - 100 mm
