PANTHER

Correa
Used bridge/gantry type milling machine, high speed in excellent condition.
Suitable for aeronautical applications thanks to its high dynamics, precision, and flexibility.
Country
Share
Ask for price On request
Condition Used - Working

Machine data

Manufacturer CORREA
Condition Used - Working
Price type On request

Technical specifications

Length 15.000 mm
Width 8.418 mm
Height 6.033 mm
Spindle speed 18.000 rpm
Spindle power 25 kW
Spindle taper HSK A63

Occasional seller

N
NC SERVICE MILLING MACHINES, S.A. Private seller
Member since 2017
33 ads online

SEND REQUEST

BELT PANTHER
BELT PANTHER
BELT PANTHER
BELT PANTHER
BELT PANTHER
BELT PANTHER
BELT PANTHER
BELT PANTHER

Year: 2003
CNC control: SIEMENS 840-D
Table dimensions: 14,000 x 2,500 mm
Number of T-slots: 10
T-slot dimensions: 22 mm
X-axis travel: 14,000 mm
Y-axis travel: 4,470 mm
Clearance between columns: 3,100 mm
Z-axis travel: 1200 mm / 220-1,420 mm
Spindle model: 5-axis "C5C" motor spindle 18,000 rpm
Tool clamping: Hydraulic
Taper: HSK 63
Spindle power: 25 kW
Speed range: 18,000 rpm
Working feeds: 30,000 mm/min
Rapid traverse (X / Y, Z): 30,000 mm/min
Maximum table load: 15,000 kg
Approximate machine weight: 135,000 kg
Machine dimensions: 15,000 x 8,418 x 6,033 mm
Enclosure
Internal and external coolant
Electronic handwheel
24-tool changer

  • Brand
  • Condition
    Used

  • Seller's country
    Spain
  • State
    Used - Functional
  • Weight
    Up to 500 kg
  • Long
    More than 5,000 mm
  • Width
    More than 3,000 mm
  • High
    More than 3,500 mm
  • X Travel
    Up to 500 mm
  • Y travel
    Up to 300 mm
  • Z travel
    More than 800 mm
  • Spindle speed
    More than 15,000 rpm
  • Spindle power
    15 - 30 kW
  • CNC spindle cone
    HSK A63
