OKUMA mod. LT 10 MY

USE 7-axis CNC lathe with double turret head and bar feeder
Country
Share
Ask for price On request
Condition Used - Working

Machine data

Condition Used - Working
Price type On request

Technical specifications

Distance between centers 960 mm
Bar capacity 65 mm
Spindle power 7,50 kW
Number of axes 5+ ejes

Occasional seller

M
MASTER GROUP Srl Private seller
Member since 2017
54 ads online

SEND REQUEST

OKUMA mod. LT 10 MY
OKUMA mod. LT 10 MY
OKUMA mod. LT 10 MY
OKUMA mod. LT 10 MY
OKUMA mod. LT 10 MY
OKUMA mod. LT 10 MY

YEAR: 2000
DISTANCE between centers: 960 mm
MAXIMUM turning length: 130 mm
MAXIMUM turning diameter: 210 mm
BAR capacity: 65 mm
SPINDLE: 50-4800 rpm; 5.5 - 7.5 kw
SPINDLE counter: 50-4800 rpm; 5.5-7.5 kw
X1 axis travel: 167 mm
X2 axis travel: 192 mm
Y axis travel: 50/30 mm
Z1 axis travel: 700 mm
Z2 axis travel: 730 mm
RAPID traverse X-Y-Z: 15/06/20 m/min
DRIVEN TURRET HEAD: 12 + 12 POS; 50-6000 rpm; 1.1-2.2 kw
CONTROL UNIT: OSP-U100L
BAR FEEDER: LNS mod. SPRINT S2
BAR DIAMETER: 65 mm
BAR LENGTH: 3000 mm
ACCESSORIES: CHIP CONVEYOR; PART CONVEYOR; PORTABLE HANDWHEEL
Note: With RADIAL No 3 and No 3 axial tools

  • Seller's country: Italy
  • State: Used - Functional
  • Spindle speed: 3,000 - 8,000 rpm
  • Spindle power: 5 - 15 kW
  • Number of axes: 5+ axes
  • Distance between points: 500 - 1,000 mm
  • Bar feed: 65 - 100 mm
  • Condition: Array
  • Weight: 0.000000
