HVM-2300

Anayak
ANAYAK HVM-2300 machining center with fixed table and moving column, equipped with Heidenhain control. Its size makes it ideal for small-dimension machining, and its rebuild guarantees the reliability of its finish.
Rebuilt milling machine for sale with warranty.
Country
Share
Ask for price On request
Condition Used - Working

Machine data

Manufacturer ANAYAK
Condition Used - Working
Price type On request

Technical specifications

Weight 21.500 kg
Length 7.230 mm
Width 6.240 mm
Height 3.460 mm
X travel 2.000 mm
Y travel 1.000 mm
Z travel 1.000 mm
Spindle speed 2.000 rpm
Spindle power 22 kW
Spindle taper ISO 50

Occasional seller

N
NC SERVICE MILLING MACHINES, S.A. Private seller
Member since 2017
33 ads online

SEND REQUEST

HVM-2300
HVM-2300
HVM-2300
HVM-2300
HVM-2300
HVM-2300
HVM-2300
HVM-2300
HVM-2300
HVM-2300

ANAYAK HVM-2300 moving column milling machine
Year of manufacture: 1991
Condition: Rebuilt
CNC control: HEIDENHAIN TNC-415
Table dimensions: 2,300 x 1,000 mm
Number of T-slots: 7
T-slot dimensions: 18 mm
Travels X/Y/Z (mm): 2000 / 1000 / 1000
Head: Universal manual (U22)
Tool clamping: Hydraulic
Taper: ISO 50
Speed range: 60 - 2,000 rpm
Spindle power: 18/22 kW
Working feeds: 10 - 3,000 mm/min
Rapid traverses: 10,000 mm/min
Maximum weight on table: 4,000 kg
Approximate machine weight: 21,500 kg
Machine dimensions: 7,230 x 6,240 x 3,460 mm
Longitudinal chip conveyor
Enclosure
Warranty: Mechanical spare parts 6 months
