Floor boring machine

Type: HP 100
Manufacturer: TOS
Made in: GO 2000
Feature:
Year 2002
Control system: Heidenhain
Spindle diameter: 100 mm
Clamping surface: 2000 x 2000 mm
Travel distances:
X: 2000 mm
Y: 1600 mm
W: 1200 mm
Table load: 25000 kg
Motor power: 10 kW
Machine dimensions L x W x H: 22000 x 2350 x 3550 mm
New ISO50 spindle taper
New SIM7 automatic electrical cabinet
Škoda Table Model E25 at GO 2002
Country
Share
Ask for price On request
Condition Used - Working

Machine data

Condition Used - Working
Price type On request

Technical specifications

Weight 25.000 kg
Length 22.000 mm
Width 2.350 mm
Height 3.550 mm
Z travel 1.200 mm
Spindle power 10 kW
Control type CNC

Occasional seller

A
Amaron s.r.o. Private seller
Member since 2017
99 ads online

SEND REQUEST

Floor boring machine

Type: HP 100
Manufacturer: TOS
Made in: GO 2000
Features:
Year: 2002
Control system: Heidenhain
Spindle diameter: 100 mm
Clamping surface: 2000 x 2000 mm
Travel distances:
X: 2000 mm
Y: 1600 mm
W: 1200 mm
Table load capacity: 25000 kg
Motor power: 10 kW
Machine dimensions L x W x H: 22000 x 2350 x 3550 mm
New ISO50 spindle taper
New automatic electrical cabinet SIM7
Škoda table Model E25 at GO 2002

  • Condition
    Used

  • Seller's country
    Czechia
  • State
    Used - Functional
  • Weight
    More than 10,000 kg
  • Long
    More than 5,000 mm
  • Width
    2,000 - 3,000 mm
  • High
    More than 3,500 mm
  • Control type
    CNC
  • X Travel
    2,000 - 3,000 mm
  • Y travel
    More than 1,000 mm
  • Z travel
    More than 800 mm
  • Spindle power
    5 - 15 kW
