VICTOR VTURN - V300

- USED - 2-AXIS CNC VERTICAL LATHE VICTOR VTURN - V300
Country
Share
Ask for price On request
Condition Used - Working

Machine data

Condition Used - Working
Price type On request

Technical specifications

Weight 6.000 kg
Length 3.235 mm
Width 1.600 mm
Height 2.805 mm
Swing diameter 600 mm
Spindle power 18,50 kW
Number of axes 2 ejes

Occasional seller

M
MASTER GROUP Srl Private seller
Member since 2017
54 ads online

SEND REQUEST

VICTOR VTURN - V300
VICTOR VTURN - V300
VICTOR VTURN - V300

YEAR: 2004
MAX ROTATING DIAMETER 600 mm
MAX TURNING DIAMETER 540 mm
SPINDLE 2500 rpm; 15-18.5 Kw; ASA 2-8
X-AXIS TRAVEL 400 mm
Z-AXIS TRAVEL 520 mm
RAPID FEEDS X-Z 15-24 m/min
TURRET HEAD 8 POS
CONTROL UNIT FANUC 18i-TB
WEIGHT: 6000 Kg
OVERALL DIMENSIONS: 1600 x 3235 x 2805 mm
ACCESSORIES: SWARF CONVEYOR; MANUAL GUIDE; PCMCIA SERIAL PORT; RS 232 SERIAL PORT; TOOL PRESETTER; PORTABLE HANDWHEEL

  • Condition
    Used

  • Seller's country
    Italy
  • State
    Used - Functional
  • Weight
    5,000 - 10,000 kg
  • Long
    3,000 - 5,000 mm
  • Width
    1,000 - 2,000 mm
  • High
    2,500 - 3,500 mm
  • Spindle speed
    Up to 3,000 rpm
  • Spindle power
    15 - 30 kW
  • Number of axes
    2 axes
  • Turning diameter
    500 - 800 mm
