CORTADORA TUBOS LYBRA C450

Diameter of the disc (mm) 350 - 400 - 450
Fastening the disc Din 8576 (mm) 50 - 4 - 14 - 80
40 - 4 - 1 1 - 63
Cutting capacity at 90 °
(without charger)
circular 100 -125 - 145
square 90 - 110 - 130
rectangular 140 × 70 - 160 × 90 - 180 × 100
Cutting capacity at 45 °
(without charger)
circular 95 - 115 - 135
square 80 - 100 - 110
rectangular 110 × 60 - 130 × 70 - 150 × 70
Cutting capacity at 30 °
(without charger)
circular 80 - 95 - 100
square 70 - 80 - 90
rectangular 110 × 60 - 130 × 70 - 150 × 70
Cutting head motor power Kw 5,5
Power pump motor oil Kw 2,2
Power pump motor lubrication Kw 0.12
Feed stroke (mm) 2,000
Working height (mm) 1,050
Weight of the machine Kg. 2,800
