NH 4000DCG

Pallet Size 15.7" x 15.7", Number Of Pallets 2, Pallet Weight Capacity 882 Lbs., Pallet Surface to Spindle Center 3.1" - 25.1",Pallet Center To Spindle Gage Line 3.9" - 28.7", Workpiece Size Diameter x Height 24.8", X - Axis Travel 22",Y - Axis Travel 22", Z - Axis Travel 24.4", B - Axis Travel 1° Index, Rapid Traverse Rates X, Y, Z 1968, 1968, 1968 IPM, Spindle Speed 14,000 RPM, Spindle Taper 40 CT, Main Motor 25 HP, Number Of Tools 60 ATC, Tool Diameter 2.7" / 5.5", Tool Length 15.7",Tool Weight 17.6 Lbs., Tool Change Time .9 Seconds, Machine Weight 21,800 Lbs., CHIP CONVEYOR AUTO TOOL SETTER, 48 PAIRS OF WORK COORDINATES 99 TOOL OFFSETS, FANUC MSX 501III CNC CONTROL 18IMB MAPPS CONVERSTIONAL PROGRAMMING, 300 PSI THRU SPINDLE COOLANT
